Parameter
1.
25mm aluminum groove
2.
Input: AC415V, 50Hz, output: 24V/3A
3.
air compressor: AC220V±10%, 50Hz, motor power: 480W,capacity: 6L, output:
0.85MPa, noise level : 66dB
4.PLC:
Siemens S7-1200
Capability
1. single acting cylinder reversing loop
2.
double acting cylinder reversing loop
3.
single acting cylinder speed control loop
4.
double acting cylinder one-way speed regulation loop
5.
double acting cylinder both-way speed regulation loop
6.
speed changing-over loop
7.
buffering loop
8.
twice pressure control loop
9.
high/low pressure converting loop
10.
counting loop
11.
delay loop
12.
overload protection loop
13.
interlocking loop
14.
single cylinder single reciprocating control loop
15.
single cylinder continuous reciprocating control loop
16.
straight line cylinder, double acting cylinder sequential action loop
17.
multi-cylinder sequential action loop
18.
two-cylinder synchronous action loop
19.
four-cylinder linked action loop
20.
unloading loop
21.
or gate type shuttle valve application loop
22.
dual pressure valve application loop
23.
quick exhaust valve application loop
