Parameter

1. input power: three phase five wire, 380V, 50Hz

2. capacity: ＜2kVA

3. variable vane pump: pressure 7Mpa, displacement 8mL/r

4.with control mode: power mode, relay control mode

5.motor: nominal voltage 380V, rated power: 0.75KW, insulation grade B

6. hydraulic power pack: maximum volume 90L, 2mm steel plate, variable vane pump and motor, the oil temperature gauge, clean cover, air cleaner, stainless steel pressure gauge, L-HL46# hydraulic oil

Capability

1. Single-stage voltage regulator circuits

2. Multistage pressure regulating circuit

3. pressure relief circuit

4. unloading circuits

5. oil inlet throttling speed control circuit

6. Oil return throttling speed control circuit

7. The oil throttling speed control circuit

8. The quick loop of hydraulic cylinder differential connection

9. compensated flow control valve short circuit speed changeover circuit

10. compensated flow control valve series connection speed changeover circuit

11. compensated flow control valve parallel connection speed changeover circuit

12. reversing valve’s reversing circuit
