Parameters

1. size: 160*70*150cm

2. working power: AC three phase four wire 380V±5%, 50Hz

3, input power: ＜1.5KVA

Configuration

1.experiment table

2.power control screen

3. experimental bin

4.two motor

5.experiment wire, experiment guidebook, experiment instruction

Capability

1.connection of contactor inching circuit and continuous rotation circuit

2.connection of positive rotation and reverse rotation control circuit of push button interlocking

3. connection of motor positive rotation and reverse rotation circuit of contactor interlocking

4. Contactor and buttons dual interlock and reversal control

5. motor stator winding series resistance start control circuit

6.button switch start button control circuit connection

7. Time relay switch start control circuit

8. Motor half-wave rectifier energy consumption braking control circuit connection

9. Motor full-wave rectifier energy consumption braking control circuit connection

10. Motor reverse connect braking control circuit connection

11. Motor training trips control circuit connection

12. Motor sequence start control circuit connection training

13. Motor timing rotation operation control circuit connection

14. Time relay switch two-speed motor control circuit connection

15.installation of Electric fan

16.control of stair light

17. daylight lamp circuit

18. Voice control switch control incandescent bulbs circuit

19. light control switch control incandescent bulbs circuit
